BMW R 1200RS 2016 User Manual

Maximum payload and
maximum speed
Observe maximum payload and
top speed as indicated on label
in topcase.
If you cannot find your combi-
nation of motorcycle and top-
case on the label, contact your
BMW Motorrad Retailer.
The following values apply to the
combination described here:
Maximum speed for rid-
ing with Vario topcase
max 112 mph (max 180 km/h)
Payload of Vario topcase
max 11 lbs (max 5 kg)
Navigation system
Fasten navigation system
securely
with preparation for navigation
system
OE
with navigation system
OA
NOTICE
The navigation preparation is
suitable for the BMW Motorrad
Navigator IV and the
BMW Motorrad Navigator V.
NOTICE
The locking system of the
Mount Cradle offers no
protection against theft.
Remove the navigation system
and store in a safe place after
every drive.
Turn ignition key 1 counter-
clockwise.
Pull shut-off lock 2 to left.
Press in locking device 3.
Mount Cradle is unlocked and
cover 4 can be removed with
a rotating movement toward
front.
9
156
z Accessories
ProCarManuals.com

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
