BMW R 1200RS 2016 User Manual

Clutch
Adjusting clutch lever
WARNING
Adjusting the clutch lever
while driving
Accident hazard
Only adjust the clutch lever
when the motorcycle is
stationary.
Turn adjusting wheel 1 into
desired position.
NOTICE
The adjustment wheel can be
turned more easily if you press
the clutch lever forward when
doing so.
Four settings are available:
Position 1: smallest distance
between handlebar grip and
clutch lever
Position 4: largest distance
between handlebar grip and
clutch lever
Brakes
Adjusting handbrake lever
WARNING
Adjusting the brake lever
while driving
Accident hazard
Only adjust the brake lever
when the motorcycle is
stationary.
Turn adjusting wheel 1 into
desired position.
NOTICE
The adjustment wheel can be
turned more easily if you press
the handbrake lever forward
when doing so.
Four settings are available:
Position 1: smallest distance
between handlebar grip and
brake lever
Position 4: largest distance
between handlebar grip and
brake lever
5
80
z Setting
ProCarManuals.com

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
