BMW R 1200RS 2016 User Manual

by an authorized BMW Motorrad
retailer.
Multifunction display
Support for menu
guidance
Arrows in the display have the
following meaning:
Arrows 1 and 3: Press and
hold the respective button.
Arrow 2: Briefly press the re-
spective button.
Setting individual display
view
Switch on ignition ( 46).
Repeatedly press button 1
briefly, until STYLE is shown
in bottom line of display 2.
Press and hold button 1 to
change Display view. The
numbers have the following
meaning information:
0: Full view
1: Sport view
2: Touring view
The selected Display view is
shown in the area 2.
Selecting view on onboard
computer
Switch on ignition ( 46).
Press button 1 briefly to select
display in top line of display 2.
In the case of standard equip-
ment, the following values can be
displayed and selected per push
of a button:
Trip odometer 1 (TRIP 1)
Trip odometer 2 (TRIP 2)
Range (RANGE)
Total mileage (ODO)
SETUP menu (SETUP), while
stationary only
with Pro onboard computer
OE
The following information is ad-
ditionally displayed using the on-
board computer Pro:
4
56
z Operation
ProCarManuals.com

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
