BMW R 1200RS 2016 User Manual

Threaded fasteners
Front wheel Value Valid
Brake caliper on telescopic
forks
M10 x 65 28 lb/ft (38 Nm)
Quick-release axle in telescopic
fork
M20 x 1.5 37 lb/ft (50 Nm)
Clamping screw for quick-re-
lease axle in telescopic fork
M8 x 50 Tighten the screws 6 times, alternating
between one and the other each time
14 lb/ft (19 Nm)
Rear wheel Value Valid
Tighten rear wheel on wheel
flange
M10 x 1.25 x 40 tighten diagonally
44 lb/ft (60 Nm)
11
169
z Technical data
ProCarManuals.com

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
