Engine oil

Engine oil, capacity max 1.1 gal (max 4 l), with filter replacement

Specification SAE 5W-40, API SL/JASO MA2, Additives (for in-

stance, molybdenum-based substances) are pro-

hibited, because they would attack the coatings

on engine components, BMW Motorrad recom-

mends BMW Motorrad ADVANTEC Ultimate Oil.

Engine oil, quantity for topping up max 1 quarts (max 0.95 l), Difference between

MIN and MAX

BMW recommends

Engine

Engine number location Lower right of engine block beneath the starter

Engine type 122EN

Engine design Air/liquid-cooled two-cylinder, four-stroke

opposed-twin engine with two spur gear-driven

overhead camshafts and one counterbalance shaft

Displacement 1170 cc (1170 cm

)

Cylinder bore 4 in (101 mm)

Piston stroke 2.9 in (73 mm)

172

Technical data

ProCarManuals.com

Questions and Answers:

Need help?

Do you have a question about the BMW R 1200RS 2016 and is the answer not in the manual?

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
