3-121
Confidential
10.4 T2 side cover R
(1) Remove the taptite bind B M4x12 screw from the front side of the T2 side cover R.
(2) Release the two front hooks, two top hooks and four bottom hooks, and remove the T2
side cover R from the LT unit.
Fig. 3-152
Hooks
Taptite bind B M4x12
Hooks
T2 side cover R
Hooks
LT unit
Hooks
