Chapter 5
5-1
5.1 Periodic Replacement Parts
5.1.1 Periodic replacement parts
0012-6595
T-5-1
5.2 Consumable Parts
5.2.1 Consumable parts
0014-9679
T-5-2
5.3 Periodic Maintenance
5.3.1 Regular Maintenance
0012-6597
T-5-3
Level Periodic Replacement part
User None
Service
Personnel
None
Level Consumables Life
sheets/A0
Parts Counter
Name Part number Q'ty Parts Unit
User See "Specifications > Features > Consumables
Service WASTE INK ABSORBER UNIT QL2-2110 1 20000 A1 A
WASTE INK ABSORBER UNIT (L) QL2-2108 2 20000 A3, A4
WASTE INK ABSORBER UNIT (S) QL2-1650 1 20000 A5
SUCTION FAN UNIT QM3-1012 1 20000 A6
DUCT QL2-1663 1 20000 A6
CARRIAGE UNIT QM3-1995 1 20000 D1, D2, D3 D
TUBE UNIT QM3-2004 1 20000 D4
PURGE UNIT QM3-1004 1 20000 H1 H
SENSOR UNIT QM3-1056 1 20000 K1 K
MOTOR, CARRIAGE QK1-2868 1 20000 M1 M
FEED MOTOR ASS'Y QM2-2502 1 20000 P1 P
FAN UNIT QM3-1038 2 20000 V1 V
Level Regular maintenance
User Cleaning of ink mist and other substances
(When necessary and when replacing the printhead)
Service personnel None
