Chapter 1

1-1

1.1 Product Overview

1.1.1 Product Overview

0014-8814

This printer is a large-format printer that prints in a maximum width of 44 inches with high-speed photographic picture quality.

This printer is a stand-mounted type printer and is capable of output to either roll media or cut sheet.

Product Components

F-1-1

T-1-1

1.2 Features

1.2.1 Features

0014-8819

- Media pass in widths up to 44 inches (1117.6 mm).

- Large ink tanks save the need for their replacement.

- Uninterrupted printing from subtanks.

- BK and MBK inks are loaded concurrently to eliminate the need for their replacement.

- Media take-up unit (option) is supported.

- Media take-up unit (option) can be mounted concurrently with a basket.

- Durability will be added by maintenance kit.

- Large LCD panel displays more information and makes operations easier.

- High resolutions of 2400 x 1200 dpi maximum, coupled with the exceptionally light-fast, water-proof and ozone-proof 12-color pigment inks of MBK, BK, PC,

C, PM, M, Y, R, G, B, GY, and PGY, deliver high-quality photographic picture quality.

- USB2.0 Hi-speed interface and 10Base-T/100Base-TX in standard support of a TCP/IP network, plus optional support of IEEE1394.

- Barcodes printed on roll media make remaining roll media management possible.

- Borderless four-side printing support (roll media) removes laborious cutting work, easing the job of creating posters to a significant degree.

- High-speed printing with a 1-inch head for each color (1,280 nozzles), under bidirectional print control.

- Ink supply through tubing to a completely independent printhead and large-capacity ink tanks.

1.2.2 Printhead

0013-2742

The printhead that mounts on the carriage is an integrated six-color disposable printhead.

It has 2,560 nozzles for each color, comprising two trays of 1,280 nozzles each arranged in a zigzag pattern.

If print quality remains unimproved even after a specified cleaning operation, replace the printhead. Replacement about one year after the date of initial unpacking

is also recommended.

[1] Upper cover [8] Roll holder

[2] Ink tank cover unit (R) [9] Ink tank

[3] Ink tank cover unit (L) [10] Printhead

[4] Operation panel [11] Belt stopper

[5] Stand (USA: Bundled/ Others: Option) [12] Hex key wrench

[6] Basket [13] Pocket

[7] Media take-up unit (Option) [14] Power cord

[1]

[4]

[2]

[3]
