Chapter 1
1-5
1.4 Detailed Specifications
1.4.1 Printing mode
0012-6230
T-1-2
*1 Uni-directional can be selected optionally from the printer driver.
1.4.2 Interface Specifications
0013-8837
a. USB (standard)
(1) Interface type
USB 2.0, Full speed (12 Mbits/sec), Hi-speed (480 Mbits/sec)
(2) Data transfer system
Control transfer
Bulk transfer
(3) Signal level
Compliant with the USB standard.
(4) Interface cable
Twisted-pair shielded cable, 5.0 m max.
Compliant with the USB standard.
Wire materials: AWG No.28, data wire pair (AWF: American Wire Gauge)
AWG No.20 to No.28, power distribution wire pair
(5) Interface connector
Printer side: Series B receptacle compliant with USB standard
Cable side: Series B plug compliant with USB standard
b. Network (standard)
(1) Interface type
Interface compliant with IEEE802.3
(2) Data transfer system
10Base-T/100Base-TX
(3) Signal level
Input: Threshold
10Base-T: Max. +585 mV, Min. +300 mV
100Base-TX: Turn-on +1000 mV diff pk-pk, Turn-off +200 mV diff pk-pk
Output:
10Base-T: +2.2 V to +2.8 V
100Base-TX: +0.95 to +1.05 V
(4) Interface cable
Category 5 (UTP or FTP) cable, 100 m or shorter
Weight Printer: Approx. 111kg
Stand: Approx. 28kg
Media take-up unit: Approx. 5kg
Media Type Print
Priority
Print Quality Processing
resolution
(dpi)
Print resolution
(dpi)
Print
pass
Printing direction
(*1)
Plain Paper
Plain Paper(High Quality)
Plain Paper(High Grade)
Image draft 300 1200x1200 2 Bi-directional
standard 300 1200x1200 4 Bi-directional
High 600 2400x1200 8 Bi-directional
Line drawing
/Text
draft 600 1200x1200 2 Bi-directional
standard 600 1200x1200 4 Bi-directional
Office
document
standard 600 1200x1200 4 Bi-directional
Recycled Coated Paper
Coated Paper
Heavyweight Coated Paper
Extra Heavyweight Coated Paper
Image standard 300 1200x1200 4 Bi-directional
High 600 2400x1200 8 Bi-directional
Highest 600 2400x1200 12 Bi-directional
Premium Matte Paper
Glossy Photo Paper
Semi-Glossy Photo Paper
Heavyweight Glossy Photo Paper
Heavyweight SemiGlos Photo Paper
Synthetic Paper
Adhesive Synthetic Paper
Backlit Film
Backprint Film
Flame-Resistant Cloth
Fabric Banner
Thin Fabric Banner
Proofing Paper
Fine Art Photo
Fine Art Heavyweight Photo
Fine Art Textured
Fine Art Watercolor
Fine Art Block Print
Canvas Matte
Canvas Semi-Glossy
Japanese Paper Washi
Image standard 600 1200x1200 6 Bi-directional
High 600 2400x1200 8 Bi-directional
Highest 600 2400x1200 16 Bi-directional
Colored Coated Paper Image standard 300 1200x1200 4 Bi-directional
High 600 2400x1200 8 Bi-directional
CAD Tracing Paper
CAD Translucent Matte Film
CAD Clear Film
Line drawing
/Text
draft 600 1200x1200 2 Bi-directional
standard 600 1200x1200 4 Bi-directional
High 600 2400x1200 8 Bi-directional
To Next Page
