Chapter 3
3-1
3.1 Installation
3.1.1 Making Pre-Checks
3.1.1.1 Making Pre-Checks
0014-8917
Follow the instructions in the included "Quick Start Guide" when installing the product.
Refer to the package size and weight listed below for smooth carrying in and installation of the product.
T-3-1
1) Installation space
Height
F-3-1
Width and depth
F-3-2
3.1.2 Unpacking and Installation
3.1.2.1 Checking the Contents
0014-8918
1) Check for the components.
a) Printer
Package size and weight
(including palette)
2070mm (W) x 1050mm (D) x 860mm (H) Approx. 168Kg
224mm
(8.8")
356mm
(14")
1500mm
(59")
[H] 1144mm
(45")
100mm
(3.9")
600mm
(23.6")
200mm
(7.9")
200mm
(7.9")
[W] 1893mm (74.5")
2293mm (90.3")
[D] 975mm
(38.4")
1675mm
(65.9")
To Next Page
