Chapter 3

3-7

F-3-15

F-3-16

The printer weighs approximately 111kg (244.7lb). Moving the printer requires at least four people, two on either side. Be careful to avoid back strain and other

injuries.

When moving the printer, firmly grasp the carrying handles under each side. Holding the printer at other positions is dangerous and may cause injury and damage

if the printer is dropped.

4) Align the triangles on the back of the printer and the stand when setting the printer on the stand. Secure the printer and the stand firmly together using four M4

hex screws on each side.

F-3-17

3.1.2.4 Installing the Basket

0014-8929

Install the basket.

1) Insert the basket arm R [1] in the hole [2] on the right side of the bottom stand stay. Insert the right side [3] of the middle basket rod in the hole [4] of the basket

arm R.
