APPENDIX A — CARRIER CONTROLLER DISPLAY TABLES (cont)
*Depends on the selected language (English by default).
VLT_DRV — VLT Drive Maintenance
Carrier Controller PATH:
Main Menu  Maintenance Menu
 VLT Drive Maintenance
LINE DISPLAYED TEXT* CCN NAME RANGE
DEFAULT
VALUE
UNIT
READ/
WRITE
1 Cir A Drive Power drv_pwra — — kW RO
2 Cir A Drive Power % drv_pwPa 0 to 100 — % RO
3 Cir A Drive Amps drv_Ia — — Amps RO
4 Comp A Amperage % drv_IPa 0 to 100 — % RO
5 Cir A Drive Voltage drv_Va — — Volts RO
6 Comp A Line voltage % drv_VPa 0 to 135 — % RO
7 Cir A Drive Speed drv_Sa — — rpm RO
8 Comp A Speed% drv_SPa 0 to 100 — % RO
9 Cir A Drive Frequency drv_Fa — — Hz RO
10 Comp A Frequency % drv_FPa 0 to 100 — % RO
11 Cir A Drive Torque drv_Ta — — — RO
12 Circ A Drive Torque % drv_TPa 0 to 100 — % RO
13 Cir A Drive DC Link Volt drv_DCVa — — Volts RO
14 Comp A DC Link Voltage % drv_DCPa 0 to 135 — % RO
15 Cir A Drive Heat Sink T drv_HSTa — — °F (°C) RO
16 Comp A Heat Sink Temp % drv_HSPa 0 to 135 — % RO
17 Cir A Drive Ctrl Card T drv_CCTa — — °F (°C) RO
18 Cir A Drive Heater drv_HTRa Off(0)/On(1) Off(0) — RO
19 Cir B Drive Power drv_pwrb — — kW RO
20 Cir B Drive Power % drv_pwPb 0 to 100 — % RO
21 Cir B Drive Amps drv_Ib — — Amps RO
22 Comp B Amperage % drv_IPb 0 to 100 — % RO
23 Cir B Drive Voltage drv_Vb — — Volts RO
24 Comp B Line voltage % drv_VPb 0 to 135 — % RO
25 Cir B Drive Speed drv_Sb — — rpm RO
26 Comp B Speed% drv_SPb 0 to 100 — % RO
27 Cir B Drive Frequency drv_Fb — — Hz RO
28 Comp B Frequency % drv_FPb 0 to 100 — % RO
29 Cir B Drive Torque drv_Tb — — — RO
30 Circ B Drive Torque % drv_TPb 0 to 100 — % RO
31 Cir B Drive DC Link Volt drv_DCVb — — Volts RO
32 Total Comp Drive Power drv_pwr — — kW RO
33 Comp B DC Link Voltage % drv_DCPb 0 to 135 0 to 100 % RO
34 Cir B Drive Heat Sink T drv_HSTb — — °F (°C) RO
35 Comp B Heat Sink Temp % drv_HSPb 0 to 135 0 to 100 % RO
36 Cir B Drive Ctrl Card T drv_CCTb — — °F (°C) RO
37 Cir B Drive Heater drv_HTRb Off(0)/On(1) Off(0) — RO
38 Drive A Attach SET_DRVA No(0)/Yes(1) No(0) — RW
39 Drive B Attach SET_DRVB No(0)/Yes(1) No(0) — RW
40 Comm with Drive A Ok VLT_COMA No(0)/Yes(1) No(0) — RO
41 Comm with Drive B Ok VLT_COMB No(0)/Yes(1) No(0) — RO
42 Force Comp Drv A Config CnfgDrva No(0)/Yes(1) No(0) — RO
43 Force Comp Drv B Config CnfgDrvb No(0)/Yes(1) No(0) — RO
LEGEND
RO — Read Only
RW — Read/Write
Spt — Set Point
