APPENDIX A — CARRIER CONTROLLER DISPLAY TABLES (cont)
*Depends on the selected language (English by default).
EXV_CTRL — EXV Control
Carrier Controller PATH:
Main Menu Maintenance Menu
EXV Control
LINE DISPLAYED TEXT* CCN NAME RANGE
DEFAULT
VALUE
UNIT
READ/
WRITE
1 Circuit A
——
———
2 EXV Override Circuit A
ov_exv_a —
——RO
3 EXV Position (Pct) A
EXV_A —
—%RO
4 EXV Position (Steps) A
EXV_STPA 0 to 10000
——RO
5 Discharge Superheat A
DSH_A —
— °F (°C) RO
6 Dis. Superheat Setpnt A
dsh_spa —
— °F (°C) RO
7 Suction Superheat A
SH_A —
— °F (°C) RO
8 Suct. Superheat Setpnt A
sh_sp_a —
— °F (°C) RO
9 Evap ExchangeDT Cir A
pinch_a —
— °F (°C) RO
10 Subcooling Circuit A
subcoola —
— °F (°C) RO
11 Subcooling Setpoint A
subc_spa —
— °F (°C) RO
12 EXV State A
exv_sta —
——RO
13 EXV Previous State A
exv_lsta —
——RO
14 EXV Wished Position A
exvwposa —
——RO
15 EXV Mode A
exv_moda Closed(0)/Open(1)
——RO
16 EXV Mode Text A
exv_txta Closed(0)/Open(1)
——RO
17 Circuit B
——
———
18 EXV Override Circuit B
ov_exv_b —
——RO
19 EXV Position (Pct) B
EXV_B —
—%RO
20 EXV Position (Steps) B
EXV_STPB 0 to 10000
——RO
21 Discharge Superheat B
DSH_B —
— °F (°C) RO
22 Dis. Superheat Setpnt B
dsh_spb —
— °F (°C) RO
23 Suction Superheat B
SH_B —
— °F (°C) RO
24 Suct. Superheat Setpnt B
sh_sp_b —
— °F (°C) RO
25 Evap ExchangeDT Cir B
pinch_b —
— °F (°C) RO
26 Subcooling Circuit B
subcoolb —
— °F (°C) RO
27 Subcooling Setpoint B
subc_spb —
— °F (°C) RO
28 EXV State B
exv_stb —
——RO
29 EXV Previous State B
exv_lstb —
——RO
30 EXV Wished Position B
exvwposb —
——RO
31 EXV Mode B
exv_modb Closed(0)/Open(1)
——RO
32 EXV Mode Text B
exv_txtb Closed(0)/Open(1)
——RO
LEGEND
RO — Read Only
RW — Read/Write
Spt — Set Point
