308
APPENDIX C — LON POINT TABLE, EXAMPLE CONFIGURATION
LEGEND
LON POINT SNVT TYPE POINT READ/WRITE CCN POINT DESCRIPTION CCN POINT NAME
CHLRMAP1
nviChillerEnable SNVT_switch POINT01 W CCN Chiller Start/Stop CHIL_S_S
nviCoolSetpt SNVT_temp_p POINT02 W Control Point CTRL_PNT
nvoOnOff SNVT_switch POINT03 R
nvoActiveSetpt SNVT_temp_p POINT04 R Control Point CTRL_PNT
nviCapacityLim SNVT_lev_percent POINT05 W Active Demand Limit DEM_LIM
nviHeatSetpt SNVT_temp_p POINT06 W
nvoActualCapacity SNVT_lev_percent POINT07 R Percent Total Capacity CAP_T
nvoCapacityLim SNVT_lev_percent POINT08 R Active Demand Limit DEM_LIM
nvoLvgCHWTemp SNVT_temp_p POINT09 R Cooler Leaving Fluid COOL_LWT
nvoEntCHWTemp SNVT_temp_p POINT10 R Cooler Entering Fluid COOL_EWT
nvoEntCNDWTemp SNVT_temp_p POINT11 R
nvoLvgCNDWTemp SNVT_temp_p POINT12 R
nvoChillerStat.run_mode SNVT_chlr_status POINT13 R
nvoChillerStat.op_mode SNVT_chlr_status POINT14 R
nvoChillerStat.in_alarm SNVT_chlr_status POINT15 R
nvoChillerStat.run_enabl SNVT_chlr_status POINT16 R
nvoChillerStat.Local SNVT_chlr_status POINT17 R
nvoChillerStat.Limited SNVT_chlr_status POINT18 R
nvoChillerStat.chw_flow SNVT_chlr_status POINT19 R
nvoChillerStat.cndw_flow SNVT_chlr_status POINT20 R
nviOccSchedule SNVT_occupancy POINT21 W
CHLRMAP2
nviTEMP1 SNVT_temp_p POINT22 W Outdoor Air Temperature OAT
nvoTEMP1 SNVT_temp_p POINT23 R Saturated Suction Temp A SST_A
nvoTEMP2 SNVT_temp_p POINT24 R Saturated Suction Temp B SST_B
nvoTEMP3 SNVT_temp_p POINT25 R
nvoTEMP4 SNVT_temp_p POINT26 R Saturated Cond Temp A SCT_A
nvoTEMP5 SNVT_temp_p POINT27 R Saturated Cond Temp B SCT_B
nvoTEMP6 SNVT_temp_p POINT28 R
nviPRESS1 SNVT_press_p POINT29 W
nvoPRESS1 SNVT_press_p POINT30 R Discharge Pressure A DP_A
nvoPRESS2 SNVT_press_p POINT31 R Discharge Pressure B DP_B
nvoPRESS3 SNVT_press_p POINT32 R
nvoPRESS4 SNVT_press_p POINT33 R
nvIPCT1 SNVT_lev_percent POINT34 W
nvIPCT2 SNVT_lev_percent POINT35 W
nvoTEMPDIFF1 SNVT_temp_diff_p POINT36 R
nvoTEMPDIFF2 SNVT_temp_diff_p POINT37 R
nviDISCRETE1 SNVT_switch POINT38 W
nviDISCRETE2 SNVT_switch POINT39 W
nvoDISCRETE1 SNVT_switch POINT40 R CCN Chiller Start/Stop CHIL_S_S
nvoDISCRETE2 SNVT_switch POINT41 R
nvoDISCRETE3 SNVT_switch POINT42 R
nvoDISCRETE4 SNVT_switch POINT43 R
nvoDISCRETE5 SNVT_switch POINT44 R
nvoDISCRETE6 SNVT_switch POINT45 R
nviCOUNT1 SNVT_count POINT46 W
nvoCOUNT1 SNVT_count POINT47 R Run Status STATUS
nvoCOUNT2 SNVT_count POINT48 R Alarm State ALM
nvoCOUNTinc1 SNVT_count_inc POINT49 R Fan Staging Number A FAN_ST_A
nvoCOUNTinc2 SNVT_count_inc POINT50 R
R—Read Only
W—Read Write
SNVT — Standard Network Variable Type
Spt —Set Point
