APPENDIX A — CARRIER CONTROLLER DISPLAY TABLES (cont)
*Depends on the selected language (English by default).
TBLSHT — Troubleshoot Info
Carrier Controller PATH:
Main Menu  Maintenance Menu  Troubleshoot Info
LINE DISPLAYED TEXT* CCN NAME RANGE
DEFAULT
VALUE
UNIT
READ/
WRITE
1 Evap Entering Fluid COOL_EWT — — °F (°C) RO
2 Evap Leaving Fluid COOL_LWT — — °F (°C) RO
3 Capacity Signal Cir A CAPT010A 0 to 100 — % RO
4 Cir A Drive Amps drv_Ia — — A RO
5 Cir A Drive Speed drv_Sa — — rpm RO
6 Saturated Cond Tmp Cir A SCT_A — — °F (°C) RO
7 Saturated Suction Temp A SST_A — — °F (°C) RO
8 Saturated Liquid Temp A SLT_A — — °F (°C) RO
9 Compressor Suction Tmp A SUCT_A — — °F (°C) RO
10 Discharge Gas Temp Cir A DGT_A — — °F (°C) RO
11 Motor Temperature Cir A CP_TMP_A — — °F (°C) RO
12 EXV Eco. Tmp Cir A ECO_T_A — — °F (°C) RO
13 Discharge Superheat A DSH_A — — °F (°C) RO
14 Suction Superheat A SH_A — — °F (°C) RO
15 Liquid Temperature A LIQ_T_A — — °F (°C) RO
16 Discharge Pressure A DP_A — — PSI (kPa) RO
17 Main Suction Pressure A SP_A — — PSI (kPa) RO
18 Oil Pressure A OP_A — — PSI (kPa) RO
19 Oil Pressure DifferenceA DOP_A — — PSI (kPa) RO
20 Oil Level Input A OIL_L_A Off(0)/On(1) Off(0) — RO
21 Oil Solenoid Output A OIL_SL_A Off(0)/On(1) Off(0) — RO
22 Economizer Pressure A ECO_P_A — — PSI (kPa) RO
23 Liquid Pressure A LIQ_P_A — — PSI (kPa) RO
24 --——-RO
25 Capacity Signal Cir B CAPT010B 0 to 100 — % RO
26 Cir B Drive Amps drv_Ib — — A RO
27 Cir B Drive Speed drv_Sb — — rpm RO
28 Saturated Cond Tmp Cir B SCT_B — — °F (°C) RO
29 Saturated Suction Temp B SST_B — — °F (°C) RO
30 Saturated Liquid Temp B SLT_B — — °F (°C) RO
31 Compressor Suction Tmp B SUCT_B — — °F (°C) RO
32 Discharge Gas Temp Cir B DGT_B — — °F (°C) RO
33 Motor Temperature Cir B CP_TMP_B — — °F (°C) RO
34 EXV Eco. Tmp Cir B ECO_T_B — — °F (°C) RO
35 Discharge Superheat B DSH_B — — °F (°C) RO
36 Suction Superheat B SH_B — — °F (°C) RO
37 Liquid Temperature B LIQ_T_B — — °F (°C) RO
38 Discharge Pressure B DP_B — — PSI (kPa) RO
39 Main Suction Pressure B SP_B — — PSI (kPa) RO
40 Oil Pressure B OP_B — — PSI (kPa) RO
41 Oil Pressure DifferenceB DOP_B — — PSI (kPa) RO
42 Oil Level Input B OIL_L_B Off(0)/On(1) Off(0) — RO
43 Oil Solenoid Output B OIL_SL_B Off(0)/On(1) Off(0) — RO
44 Economizer Pressure B ECO_P_B — — PSI (kPa) RO
45 Liquid Pressure B LIQ_P_B — — PSI (kPa) RO
46 Comm with Cmp VFD A Ok VLT_COMA No(0)/Yes(1) — — RO
47 Comm with Cmp VFD B Ok VLT_COMB No(0)/Yes(1) — — RO
48 Comm with Fan VFD A1 Ok FD_COMA1 No(0)/Yes(1) — — RO
49 Comm with Fan VFD A2 Ok FD_COMA2 No(0)/Yes(1) — — RO
50 Comm with Fan VFD A3 Ok FD_COMA3 No(0)/Yes(1) — — RO
51 Comm with Fan VFD B1 Ok FD_COMB1 No(0)/Yes(1) — — RO
52 Comm with Fan VFD B2 Ok FD_COMB2 No(0)/Yes(1) — — RO
53 Comm with Fan VFD B3 Ok FD_COMB3 No(0)/Yes(1) — — RO
LEGEND
RO — Read Only
RW — Read/Write
Spt — Set Point
