Carrier AquaForce 30XV400 User Manual

281
APPENDIX B — CCN POINT TABLE
See Legend on page 307.
Status/GENUNIT - General Parameters
DESCRIPTION VALUE UNITS POINT NAME
TRANSLATOR
ACCESSIBLE
NETWORK
ACCESS
Machine Control Methods 0=Local
1=Net
2=Remote
CTRL_TYP Y RO
Run Status Off/Running/Stopping/Delay/Tripout/
Ready/Override/Test
STATUS Y RW
CCN Chiller STOP/START CHIL_S_S Y RW
Occupied NO/YES CHIL_OCC Y RW
Minutes Left for Start N.N min min_left Y RO
Setpoint Select
0=Auto
1=Setpoint 1
2=Setpoint2
SP_SEL Y
RO
RO
RW
Setpoint Occupied NO/YES SP_OCC Y RW
Percent Total Capacity 0 to 100 % CAP_T Y RW
Current Setpoint °F (°C) SP Y RO
Control Point Range: -4 to 153 (-20 to 67.2)
Default: 0
°F (°C) CTRL_PNT Y RW
Emergency Stop Disable/Enable EMSTOP Y RW
Active Demand Limit Val 0 to 100 % DEM_LIM Y RW
Demand Limit Minimum 0 to 100 % min_lim Y RW
SW Version VERS_ID N RO
Status/INPUTS - Inputs Status
DESCRIPTION VALUE UNITS POINT NAME
TRANSLATOR
ACCESSIBLE
NETWORK
ACCESS
Remote On/Off Switch Close/Open ONOFF_SW Y RO
Remote Setpoint Switch Close/Open SETP_SW Y RO
Limit Switch 1 Close/Open LIM_SW1 Y RO
Limit Switch 2 Close/Open LIM_SW2 Y RO
Oil Level Input A Close/Open OIL_L_A Y RO
Oil Level Input B Close/Open OIL_L_B Y RO
Remote Reset Setpoint mA SP_RESET Y RO
Remote Dem. Limit mA LIM_ANAL Y RO
Leakage Detector 1 Volts leak_v Y RO
Leakage Detector 2 Volts leak_2_v Y RO
Customer Interlock Close/Open REM_LOCK Y RO
Ice Done Storage Switch Close/Open ICE_SW Y RO
Occupied Override Switch Close/Open OCC_OVSW Y RO
Evap Heater Detector Close/Open HEATR_SW Y RO
