APPENDIX A — CARRIER CONTROLLER DISPLAY TABLES (cont)
*Depends on the selected language (English by default).
M_MSTSLV — Master Slave Control
Carrier Controller PATH:
Main Menu  Maintenance Menu
 Master Slave Control
LINE DISPLAYED TEXT* CCN NAME RANGE
DEFAULT
VALUE
UNIT
READ/
WRITE
1 MASTER/SLAVE CONTROL — — — — —
2
Unit is Master or Slave mstslv Disable(0)/
Enable(1)
Disable(0) — RO
3 Master Control Type ms_ctrl — — — RO
4 Master/Slave Ctrl Active ms_activ False(0)/True(1) False(0) — RO
5 Lead Unit is the: lead_sel Master(0)/Slave(1) Master(0) — RO
6 Slave Chiller State slv_stat — — — RO
7 Slave Chiller Total Cap slv_capt 0 to 100 — % RO
8 Lag Start Delay l_strt_d — — min RO
9 Lead/lag Hours Delta ll_hr_d — — hours RO
10 Lead/lag Changeover? ll_chang No(0)/Yes(1) No(0) — RO
11 Lead Pulldown ? ll_pull No(0)/Yes(1) No(0) — RO
12 Master/Slave Error ms_error — — — RO
13 Max Available Capacity ? cap_max No(0)/Yes(1) No(0) — RO
14 Slave lagstat lagstat — — — RO
15 Slave Operating Hours slav_hr — — hours RO
16 Slave Evap Ent. Fluid slav_ewt — — °F (°C) RO
17 Slave Evap Leav. Fluid slav_lwt — — °F (°C) RO
ECO_CTRL — EXV Eco. Control
Carrier Controller PATH:
Main Menu  Maintenance Menu
 EXV Eco. Control
LINE DISPLAYED TEXT* CCN NAME RANGE
DEFAULT
VALUE
UNIT
READ/
WRITE
1 EXV Eco Pos. (Pct) A eco_a 0 to 100 — % RO
2 EXV Eco Pos. (Steps) A eco_stpa 0 to 10000 -— - RO
3 Eco Suction Superheat A eco_sh_a — — °F (°C) RO
4 Eco Suction SH Setpt A esh_sp_a -— -— °F (°C) RO
5 EXV Eco State A eco_sta — — — RO
6 EXV Eco Previous State A eco_lsta -— -— -— RO
7 EXV Eco Wished Pos A ecowposa — — — RO
8 EXV Eco Mode A eco_moda -— -— -— RO
9 EXV Eco Mode Txt A eco_txta — — — RO
10 EXV Eco Pos. (Pct) B eco_b 0 to 100 -— % RO
11 EXV Eco Pos. (Steps) B eco_stpb 0 to 10000 — - RO
12 Eco Suction Superheat B eco_sh_b — -— °F (°C) RO
13 Eco Suction SH Setpt B esh_sp_b -— — °F (°C) RO
14 EXV Eco State B eco_stb — -— — RO
15 EXV Eco Previous State B eco_lstb -— — -— RO
16 EXV Eco Wished Pos B ecowposb — -— — RO
17 EXV Eco Mode B eco_modb -— — -— RO
18 EXV Eco Mode Txt B eco_txtb — -— — RO
LEGEND
RO — Read Only
RW — Read/Write
Spt — Set Point
