217
No. Item Operation
1 Positioning
quality
Displays the subject of positioning. “GPS” is displayed if the power to the
GPS Module is on.
2 Selection
method
“Auto” is displayed if the power to the GPS Module is on.
3 Positioning
status
Indicates the reliability of the positioning data, as “3D”, “2D”, or
“Unknown”.
The sequence is “3D” > “2D” > “Unknown”.
4 Reception
time
Displays the satellite from which the signal was received, and result of
time setting.
5 S/N ratio The satellite number is shown on the left while the signal strength of that
satellite’s signal is indicated in the bar.
The stronger the signal is, the further the bar is displayed towards the
right edge of the screen.
Position display
No. Item Operation
1 Latitude Displays the latitude of the positioning result.
2 Longitude Displays the longitude of the positioning result.
3 Direction Displays the traveling direction of the positioning result.
4 Speed Displays the traveling speed of the positioning result.
5 Always display
North at top
With this checked, the displayed direction is always shown with north
on top.
When unchecked, the satellite position is not displayed.
6 Display satellite With this checked, the satellite position is displayed as a white circle
containing the satellite’s number.
When unchecked, the satellite position is not displayed.
7 Display direction
mark
With this checked, the traveling direction is displayed as a red arrow.
When unchecked, the red arrow is not displayed.
