32
2.5.1 LED control
The main functions are as follows.
For details of the library, refer to the System Library Manual.
(1) User notification LED
This is used for alarm notification, etc. Use as the scanner scanning LED has priority for lighting.
This LED can be controlled from the OS, which can make it light for a set period.
Item Specification Remarks
Blink interval Blinking red, on for 1 second, off for 2 seconds
Time continuously ON 30 minutes (off when VDET is detected.)
Note) This function is only usable on WEC7 models.
(2) Scanner scanning LED
This is used for notification of a scanning result.
Item Specification Attribute
Scanning successful On in green for a specified period of time, then off. L_SCANOK
Scan error On in red for a specified period of time, then off. L_SCANERR
(3) W-LAN connection status LED
This is used for notification of W-LAN wireless connection status.
Item Specification Attribute
Connection established
via SS wireless
On in orange for 1 second, off for 2 seconds L_WLAN
Time continuously ON
– Use as the scanner scanning LED has priority.
– W-LAN wireless, W-WAN, and GPS all control the LED in the same color category, so the have
the same lighting specification.
