Cisco 8831 Administration Guide

•
App Load ID: Identifies the firmware running on the conference phone.
•
Active load:xxx: Current active firmware running on the conference phone.
•
Inactive load: xxx: Inactive firmware kept on the conference phone.
•
Last Upgrade: <time date>: Time and date for last firmware upgrade
•
Active Server: xxx: Current active server.
•
Stand-by-Server:xxx: Current stand by server.
•
Mic 1: (xx) connected/disconnected: Mic connection state
•
Mic 2: (xx) connected/disconnected: Mic connection state
•
Wireless Mic 1ID: Mic ID
•
Wireless Mic 2ID: Mic ID
•
System ID:xxx: System ID
•
Linked Mode: ON/OFF: Linked mode state
•
Backlight On Time: <time>: Back light on time
•
Backlight On Duration: <time>: Back light on duration
•
Days Backlight Not Active: <days>: Days of the week when backlight is inactive
Display the Model Information screen
The Model Information screen includes the options described in Model Information Settings.
Procedure
Step 1
To display the Model Information screen, press the Settings button and then select Model Information.
Step 2
To exit the Model Information screen, press Exit.
Status menu
The Status menu includes these options, which provides information about the conference phone and its
operation:
•
Network Statistics: Displays the Network Statistics screen, which shows Ethernet traffic statistics.
•
Call Statistics: Displays information about the last call on the conference phone.
•
Device Information: Displays device settings and related information for the conference phone.
Cisco Unified IP Conference Phone 8831 Administration Guide for Cisco Unified Communications Manager
9.0
108
Model information, status, and statistics
Display the Model Information screen
