ComAp InteliPro User Manual

InteliPro, SW version 1.4, ©ComAp – April 2014
InteliPro 1.4 Comprehensive Guide - rev. 1
4-48
Min. measured voltage
Sync Check: 30 V
Max. measured voltage
NVD: 340V
Sync Check: 589 V
Voltage accuracy
1% of nominal voltage at20°Cand50or60Hz1,5%onthe
complete frequency and temperature range. For accurate NVD
measurement it is necessary that voltage with identical frequency is
connected to the Mains Voltage terminals all the time.
Remote communication interface
RS232
Optional using the plug-in module IL-NT-RS232, D-SUB9M socket
RS485
Optional using the plug-in module IL-NT-RS232-485, plug-in
terminal block
Baud rate
Depending on selected mode (up to 57600 bps)
USB
Optional using the plug-in module IL-NT-S-USB
Ethernet
Optional using the plug-in module IB-Lite
Extesion modules interface
Type
CAN bus
Galvanic insulation
Insulated, 500V
Baud rate
250kbps
Bus length
max. 200m
Termination resistor
120Ohm, built-in, jumper activated
Interface to other controllers
Type
CAN bus, available in MINT type only
Galvanic insulation
Insulated, 500V
Baud rate
250kbps
Bus length
max. 200m
Termination resistor
120Ohm, built-in, jumper activated
Relay Card CT2-REL2
The module is delivered as a default part of the InteliPro unit.
Relay contacts (terminals
RE11, RE14 and RE21, RE24)
Number of relay outputs
2
Type
Dry contacts
Operating voltage
250 VAC
Max switched voltage/current
250 V / 10A
Current measurement inputs
2 x 1ph current measurement
Measurement type
True RMS
Number of current inputs
2
Input 1 (CT k1, l1):
Current range
50 mA
