ComAp InteliPro User Manual

InteliPro, SW version 1.4, ©ComAp – April 2014
InteliPro 1.4 Comprehensive Guide - rev. 1
3-8
IL-NT-RS232-485 MODULE
IL-NT-S-USB
This module contains USB slave port connected internally to the COM1 of the controller and is
designed as an easy removable service module.
This module requires a FTDI USB Serial converter driver installed in the PC. The driver creates a
virtual serial port (COM) in the PC, which must be used in LiteEdit as communication port when a
connection is being opened.
NOTE:
The FTDI driver is installed together with LiteEdit.
NOTE:
When the USB cable from the controller is plugged-in first time into different USB ports on the PC
including USB hubs, it can be recognized as new hardware and the drivers are installed again with
different number of the virtual serial port.
CAUTION!
Use shielded USB cable only!
IL-NT-AIO
IL-NT-AIO is an extension plug-in module with four configurable analog inputs for the sensors (in the
range 0-2400 ohm; 0/4-20mA; 0-4VDC) and one configurable analog output for the sensor (in the
