ComAp InteliPro User Manual

InteliPro, SW version 1.4, ©ComAp – April 2014
InteliPro 1.4 Comprehensive Guide - rev. 1
4-26
Default setting: 10 %In
Q Min [%S]
Threshold for the reactive power measurement
Step: 1 %S
Range: 1 – 10 %S
Default: 5 %S
QU Del 1 [s]
Time delay for opening the GCB (CB1)
Step: 0,01 s
Range: 0,00 – 1,00 s
Default: 0,50 s
QU Del 2 [s]
Time delay for opening the MCB (CB2)
Step: 0,01 s
Range: 1,00 – 2,00 s
Default: 1,50 s
QU Trp Gen [Trp 1 / Trp 2 / Trp 1+2 / None]
Selection of trip binary output for QU protection
Default: None
QU Trp Mns [Trp 1 / Trp 2 / Trp 1+2 / None]
Selection of trip binary output for QU protection
Default: None
f<>
f>, f>>, f<, f<< [Hz]
Threshold of 1st and 2nd stage overfrequency and 1st and 2nd stage underfrequency protection
respectively.
Step: 0,01 Hz
Range: 0,00 - 70,00 Hz
0 = OFF, the appropriate stage of frequency protection is disabled
Default setting:
 f> 51,5 Hz
 f>> 52 Hz
 f< 47,5 Hz
 f<< 47 Hz
f> del, f>> del, f< del, f<< del [s]
Delay of the appropriate stage of the frequency protection.
Step: 0,01 s
Range: 0,00 - 600,00 s
Default setting:
 f> Del 90,00 s
 f>> Del 0,50 s
 f< Del 20,00 s
