ComAp InteliPro User Manual

InteliPro, SW version 1.4, ©ComAp – April 2014
InteliPro 1.4 Comprehensive Guide - rev. 1
4-25
Dyn Volt
V Lim 1, V Lim 2, V Lim 3 [% Un]
Voltage limits determining the Dyn Volt Prot curve.
Step: 1 %Un
Range: 0 - 100 %Un
Default setting:
- V Lim 1 30%Un
- V Lim 2 70%Un
- V Lim 3 90%Un
Delay 1, Delay 2, Delay 3 [s]
Time delays determining the Dyn Volt Prot curve.
Step: 0,01 s
Range: 0,01 – 10,00 s
Default setting:
- Delay 1 0,15 s
- Delay 2 0,70 s
- Delay 3 1,50 s
Reset Time [s]
Time delay after which the protection starts to follow the curve from the beginning.
Step: 0,01 s
Range: 0,00..10,00 s
Default setting: 2,00 s
DynVoltTrpBO [Trp 1 / Trp 2 / Trp 1+2 / None]
Selection of trip binary output for Dynamic Voltage protection.
Default setting: None
QU
V< [%Un]
Threshold for voltage measurement
Step: 1 %Un
Range: 80 – 90 %Un
Default setting: 85 %Un
Rst V< [%Un]
Threshold for voltage measurement hysteresis
Step: 1 %Un
Range: 90 – 100 %Un
Default setting: 95 %Un
I Min [%In]
Threshold for current measurement
Step: 1 %In
Range: 2 – 20 %In
