Library of setpoints
Password protection
Each setpoint can be protected by password against unauthorized change. The password protection
can be assigned to the setpoints during the configuration procedure. See the chapter Control and
navigation Pushbuttons - basic operation for instructions how to enter and modify password. See also
LiteEdit help to learn about working with password in LiteEdit.
Basic Settings
ControllerName
User defined name, used for InteliPro identification. ControllerName is max 14 characters long and
has to be entered manually using LiteEdit software.
Default setting: InteliPro
Mains CT Ratio [A/5A]
Mains current transformers ratio.
Step: 1 A/5A
Range: 1 – 25000 A/5A
Default setting: 400 A/5A
Mains CT Polar [FORWARD / REVERSE]
In case the current transformers are wired with an opposite polarity and the change of the wiring is not
possibletheusercanswitchthesigntothe“right”(opposite)polarityinordertohavethecorrect
direction. This will influence the sign of all variables related to current measurement.
FORWARD: does not have any effect on the measured current, use in case of correct wiring
REVERSE: the sign of the measured current will be switched, use in case of opposite wiring
Default setting: FOEWARD
EF CT Ratio [A/5A]
Current transformer ratio for earth fault current.
Step: 1 A/5A
Range: 1 – 8000 A/5A
Default setting: 400 A/5A
Mains PT Ratio [V/V]
Mains potential (voltage) transformers ratio.
Step: 0,01 V/V
Range: 0,01 – 500,00 V/V
Default setting: 1,00 V/V
Gen PT Ratio [V/V]
Generator potential (voltage) transformer ratio.
Step: 0,1 V/V
Range: 0,1 - 500,0 V/V
Default setting: 1,0 V/V
NomVolts Ph-N [V]
Nominal mains voltage (phase to neutral).
Step: 1 V
Range: 80 – 34000 V
Default setting: 231 V
