ComAp InteliPro User Manual

InteliPro, SW version 1.4, ©ComAp – April 2014
InteliPro 1.4 Comprehensive Guide - rev. 1
4-30
I> V Trp BO [Trp 1 / Trp 2 / Trp 1+2 / None]
Selection of trip binary output for time overcurrent protection with voltage control.
Default setting: None
I Unb
I Unb [%In]
Threshold of current unballance protection. Protection is evaluated as maximum difference between
any of the phase currents and the average value of phase currents.
Step: 1 %
Range: 0 - 200 %
Default setting: 50 %
IMinDiffEval [%In]
Minimum limit of measured current in % of nominal current, that the current unballance is enabled
from. The value is evaluated as an average value of all phase currents.
Step: 1 %
Range: 0 - 100 % of NominMainsCurr
Default setting: 50 %
I Unb Del [s]
Delay of current unbalance protection.
Step: 0,1 s
Range: 0.0 - 600 s
Default setting: 5,0 s
I> V Trp BO [Trp 1 / Trp 2 / Trp 1+2 / None]
Selection of trip binary output for current unballance protection.
Default setting: None
DOC
NominGenCurr [A]
Nominal current of the generator(s) connected to the mains feeder, protected by the InteliPro unit.
Serves for directional overcurrent protection evaluation.
Step: 1 A
Range: 1 - 32000 A
Default setting: 288 A
DOC> [%In]
Threshold for directional overcurrent evaluation as the % level of NominGenCurr.
Step: 1 %
Range: 0 - 150 %
0 = OFF, the directional overcurrent protection is disabled
Default setting: 50 %
DOC> Del [s]
Delay for directional overcurrent.
Step: 0,1 s
Range: 0,0 - 30 s
Default setting: 5,0 s
