Vector Sensor Reference Manual 63
r Description
0 ON
1 OFF
When the ‘,OTHER’ data field is specified (without the square brackets), this command will enact a
change in the RD1 message on the other port.
6.3.2 $JAIR
This command allows you to place the primary GPS engine within the Vector PRO into AIR mode
HIGH, where the receiver is optimized for the high dynamic environment associated with airborne
platforms. JAIR defaults to normal (NORM) and this setting is recommended for most
applications. Turning AIR mode on to HIGH is not recommended for Vector PRO operation.
The format of this command follows.
$JAIR,r<CR><LF>
Where feature status variable, ‘r’, may be one of the following values.
r Description
0 NORM
1 HIGH
The Vector Sensor will reply with the following response.
$>
6.3.3 $JASC,VIRTUAL
When using an external correction source, this command is used to ‘daisy chain’ RTCM data from
being input from one port and output through the other. For example, if RTCM is input on Port
B, this data will correct the position and also be output through Port A. The Vector Sensor acts as
a pass-through for the RTCM data. Either port may be configured to accept RTCM data input and
this command then allows the opposite port to output the RTCM data.
To configure the Vector Sensor to output RTCM data on the current port from data input on the
other port, issue the following command.
$JASC,VIRTUAL,r<CR><LF>
To configure the Vector Sensor to output RTCM data on the other port from RTCM data input
on the current port, issue the following command.
$JASC,VIRTUAL,r,OTHER<CR><LF>
Where the message status variable, ‘r’, may be one of the following.
r Description
