xStack
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
138
DHCP/BOOTP Relay Interface Settings
The DHCP/ BOOTP Relay Interface Settings allows the user to set up a server, by IP address, for relaying DHCP/ BOOTP
information to the Switch. The user may enter a previously configured IP interface on the Switch that will be connected directly to
the DHCP/BOOTP server using the following window. Properly configured settings will be displayed in the BOOTP Relay
Table at the bottom of the following window, once the user clicks the Add button under the Apply heading. The user may add up
to four server IPs per IP interface on the Switch. Entries may be deleted by clicking it’s corresponding
. To enable and
configure DHCP/BOOTP Relay Global Settings on the Switch, click Configuration > Layer 3 IP Networking >
DHCP/BOOTP Relay > DHCP/BOOTP Relay Interface Settings:
Figure 6- 122. DHCP/BOOTP Relay Interface Settings and DHCP/BOOTP Relay Interface Table window
The following parameters may be configured or viewed.
Parameter Description
Interface
The IP interface on the Switch that will be connected directly to the Server.
Server IP
Enter the IP address of the DHCP/BOOTP server. Up to four server IPs can be configured
per IP Interface
