xStack
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
205
value is one second.
Record Number
Select number of times the Switch will be polled between 20 and 200. The default value is
200.
Click Clear to refresh the graph. Click Apply to set changes implemented.
CPU Utilization
The CPU Utilization window displays the percentage of the CPU being used, expressed as an integer percentage and calculated
as a simple average by time interval. To view this window, click Monitoring > CPU Utilization.
Figure 8- 2. CPU Utilization window
Click Apply to implement the configured settings. The window will automatically refresh with new updated statistics
The information is described as follows:
Parameter Description
Time Interval
Select the desired setting between 1s and 60s, where "s" stands for seconds. The default
value is one second.
Record Number
Select number of times the Switch will be polled between 20 and 200. The default value is 20.
Utilization
Check whether or not to display Utilization.
Memory Usage
The Memory Usage window displays the percentage of the CPU Memory being used. To view this window, click Monitoring >
Memory Usage.
