xStack
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
230
Type
Specify the purpose of the firmware:
Download: Clicking this radio button will specify a download to the Switch. This will be the
firmware that the Switch will immediately use.
Update: Clicking this radio button will save the firmware to the Switch's memory but not
configure the Switch for this firmware. The Switch may hold two firmware versions specified
as Section 1 and Section 2.
Information about firmware on the Switch can be viewed in the Firmware Management table in the same window. It holds the
following information:
Parameter Description
ID
The user-defined Section ID of the firmware on the Switch.
Boot Status
The firmware that is currently being run on the Switch will be identified in this field with the term
"Boot".
Version
The runtime version of the firmware.
Size
The size of the firmware, in bytes.
Date
The date that the firmware was added to the Switch.
From
The IP address of the Server from which the firmware came.
User
The name of the user who downloaded the firmware.
Set Boot
Click the Apply button in this field to set the firmware version to be used upon the next boot up of
the Switch.
Delete
Click the X in this column to permanently delete the corresponding firmware from the Switch.
Download Configuration File
To download a settings file from a TFTP server, click Maintenance > TFTP Service > Download Configuration File:
Figure 9- 2. Download Settings from TFTP Server window
Enter the IP address of the TFTP server and specify the location of the switch settings file on the TFTP server.
Click Start to record the IP address of the TFTP server and to initiate the file transfer.
Upload Configuration
To upload the switch settings to a TFTP server, click Maintenance > TFTP Services > Upload Configuration:
Figure 9- 3. Upload Settings to TFTP Server window
Enter the IP address of the TFTP server and the path and filename for the switch settings on the TFTP server.
Click Start to record the IP address of the TFTP server and to initiate the file transfer.
