D-Link Verizon DSL-2750B User Manual

10DSL-2750B User Guide
Connect your Gateway
12VDC IN
POWERON/OFF
WLAN
RESET
USBLAN4DSL LAN3 LAN2 LAN1
DSL-2750B Gateway
Desktop Computer
1. Connect an RJ-11 (phone) cable from your wall phone jack to the DSL port on the back of the DSL-2750B gateway.
2. Connect an Ethernet cable from the LAN1 port on the back of the DSL-2750B to the Ethernet port on your
computer.
3. Connect the supplied power adapter into the power receptor on the back of the DSL-2750B gateway to a power
outlet or a surge protector (recommended).
4. Once you connect the power adapter, press the ON/OFF button on the back of the gateway to turn the unit on.

D-Link Verizon DSL-2750B Specifications

General

Brand	D-Link
Model	Verizon DSL-2750B
Category	Gateway
Language	English
