2. Adhere the eDP/display cable to the display back cover.
3. Adhere the conductive tape and route the eDP/display cable to the display back cover.
Next steps
1. Install the display panel.
2. Install the display bezel.
3. Install the display assembly.
4. Install the WWAN card.
5. Install the Wireless card.
6. Install the base cover.
7. Install the microSD card.
8. Install the SIM card.
9. Follow the procedure in After working inside your computer.
Sensor board
Removing the sensor board
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SIM card.
3. Remove the microSD card.
4. Remove the base cover.
5. Remove the Wireless card.
6. Remove the WWAN card.
7. Remove the display assembly.
8. Remove the display bezel.
9. Remove the display panel.
About this task
NOTE: This procedure applies only to computers shipped with a sensor board.
The following image indicates the location of the sensor board and provide a visual representation of the removal procedure.
Removing and installing components
111
