Dell P104F Service Manual

Steps
1. Align the notch on the memory module with the tab on the memory-module slot.
2. . Slide the memory module firmly into the slot at an angle and press the memory module down until it clicks into place.
NOTE: If you do not hear the click, remove the memory module and reinstall it.
NOTE: Repeat step 1 to step 4 to install any other memory modules in your computer.
NOTE: For 4G/5G WWAN configuration, the re-usable absorbers need to be transferred to the DIMM1/DIMM2 slot
while replacing the system board.
Next steps
1. Install the base cover.
2. Install the microSD card.
3. Install the SIM tray.
4. Follow the procedure in After working inside your computer.
Dummy hard-drive filler
Removing the dummy hard-drive filler
Prerequisites
1. Follow the procedure in Before working inside your computer.
Removing and installing components
39
