2. Route the down-firing speaker cables through their routing guides on the palm-rest and keyboard assembly.
3. Connect the touchpad cable to its connector (TP1) on the system board.
NOTE: The touchpad cable should be folded over the speaker and antenna cables during the connection procedure.
4.
Connect the down-firing speaker cables to their connector (SPK1) on the system board.
Next steps
1. Install the battery.
2. Install the base cover.
3. Follow the procedure in After working inside your computer.
Display assembly
Removing the display assembly
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
NOTE:
Ensure that your computer is in Service Mode. For more information, see step 6 in Before working inside your
computer.
2. Remove the base cover.
About this task
The following image(s) indicate the location of the display assembly and provides a visual representation of the removal
procedure.
Removing and installing Field Replaceable Units (FRUs)
57
