Installing the display bezel
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the display bezel and provides a visual representation of the installation procedure.
Figure 54. Installing the display bezel
Steps
NOTE:
While installing the replacement display bezel for the models that are shipped with a camera, carefully peel off the
piece of tape that is used to secure the camera shutter to the replacement display bezel.
CAUTION: The tape covering the camera on the replacement display bezel must be peeled carefully. An abrupt
peeling may remove the camera shutter from the display bezel and damage the camera shutter.
1. Align and place the display bezel on the display assembly.
2. Gently snap the display bezel into place.
Next steps
1. Install the display assembly.
2. Install the base cover.
3. Follow the procedure in After working inside your computer.
Removing and installing Field Replaceable Units (FRUs)
85
