Delta DVP-SS2 User Manual

3. Instruction Set
3-3
3.1 Basic Instructions (without API numbers)
Instruction Function Operand
Execution speed
(us)
Steps
ES2/EX2/EC5
/SS2SA2/SX2
SE
LD
Load NO contact
X, Y, M, S, T, C
0.76
0.64
1~3
LDI
Load NC contact
X, Y, M, S, T, C
0.78
0.68
1~3
AND
Connect NO contact in series
X, Y, M, S, T, C
0.54
0.58
1~3
ANI
Connect NC contact in series
X, Y, M, S, T, C
0.56
0.62
1~3
OR
Connect NO contact in parallel
X, Y, M, S, T, C
0.54
0.62
1~3
ORI
Connect NC contact in parallel
X, Y, M, S, T, C
0.56
0.64
1~3
ANB
Connect a block in series
N/A
0.68
0.68
1
ORB
Connect a block in parallel
N/A
0.76
0.76
1
MPS
Start of branches. Stores current
result of program evaluation
N/A
0.74 0.68 1
MRD
Reads the stored current result
from previous MPS
N/A
0.64 0.54 1
MPP
End of branches. Pops (reads and
resets) the stored result in
previous MPS
N/A
0.64 0.54 1
OUT
Output coil
Y, S, M
0.88
0.68
1~3
SET
Latches the ON status
Y, S, M
0.76
0.68
1~3
RST Resets contacts, registers or coils
Y, M, S, T, C, D,
E, F
2.2 1.04 3
MC
Master control Start
N0~N7
1
0.8
3
MCR
Master control Reset
N0~N7
1
0.8
3
END
Program End
N/A
1
0.8
1
NOP
No operation
N/A
0.4
0.5
1
P
Pointer
P0~P255
0.4
0.5
1
I
Interrupt program pointer
I□□□
0.4
0.5
1
STL
*1
Step ladder start instruction
S
2.2
2
1
RET
*1
Step ladder return instruction
N/A
1.6
1.4
1
NP
Negative contact to Positive
contact
N/A 1.66 0.72 1
PN
Positive contact to Negative
contact
N/A 1.62 0.72 1
Note:
*1: Refer to section 5.1 for more information on instructions STL and RET.
*2: The execution speed is obtained by basic test programs, therefore the actual instruction
execution time could be longer due to a more complicated program, e.g. program contains multiple
interruptions or high speed input/output.
