4. Communications
4-19
4.5.7 Command Code: 16, Set content of multiple registers
Example: Set register T0 to 00 0A , T1 to 01 02 .
PC→PLC “: 01 10 06 00 00 02 04 00 0A 01 02 D6 CR LF”
Sent message:
Field Name
ASCII
STX
:
Slave Address
01
Command code
10
Starting Address Hi
06
Starting Address Lo
00
Number of Register Hi
00
Number of Register Lo
02
Byte Count
04
Data Hi
00
Data Lo
0A
Data Hi
01
Data Lo
02
Error Check (LRC)
D6
END 1
0D(Hex)
END 0
0A(Hex)
PLC→PC “: 01 10 06 00 00 02 E7 CR LF”
Feedback message:
Field Name
ASCII
STX
3A
Slave Address
01
Command code
10
Starting Address Hi
06
Starting Address Lo
00
Number of Registers Hi
00
Number of Registers Lo
02
Error Check (LRC)
E7
END 1
0D (Hex)
END 0
0A (Hex)
