Delta DVP-SS2 User Manual

Appedndix B Setting and Using an Ethernet PLC/Module
B-15
B.5.2 EtherNet/IP Objects Supported by DVP-SE / ES2-E Series PLCs
(1) Identity Object (0x01)
Instance: 0x01
Attribute
Name
Access
Data Type
Value
0x01 Vendor ID Get UINT
799
(Delta Electronics, inc.)
0x02 Device Type Get UINT
14 (Programmable Logic
Controller)
0x03
Product Code
Get
UINT
Product code
0x04
Revision
Get
STRUCT of:
Device version; Display
as Major.Minor
Major
USINT
Major: 0x01~0x7F
Minor
USINT
Minor: 0x01~0xFF
0x05
Status
Get
WORD
0 (Owned )
0x06 Serial Number Get UDINT
Serial number: the last 4
digits of the MAC
address, ab
：
cd
0x07
Product Name
Get
SHORT_STRING
Module Name
0x08 State Get UINT
0x03 (ES2-E & DVP26SE
Only)
(2) Message Router (0x02)
Instance: 0x01
Attribute
Name
Access
Data Type
Value
0x02
Number Available
Get
UINT
0
0x03
Number Active
Get
UINT
0
(3) Assembly (0x04)
Explicit message
DVP12SE: Conformance Test is not supported.
Instance
Attribute
Name
Access
Data Type
Data
0x65
0x03
D Block 1
Set
10 words
D500~D509
0x66
D Block 2
Set
30 words
D510~D539
0x67
D Block 3
Set
60 words
D540~D599
0x68
D Block 4
Set
100 words
D600~D699
0x69
D Block 5
Set
100 words
D700~D799
0x6A
D Block 6
Set
100 words
D800~D899
0x6B
D Block 7
Set
100 words
D900~D999
ES2-E & DVP26SE
Connection
No.
Name
Instance
Attribute
Data Length
Default
Connection 1
Input
0x65
100 words
D0 ~ D99
Output
0x64
100 words
D3000 ~ D3099
Configuration
0x80
8 words
Refer to Config Data below
Connection 2
Input
0x67
100 words
D100 ~ D199
Output
0x66
100 words
D3100 ~ D3199
Configuration
0x81
8 words
Refer to Config Data below
Connection 3
Input
0x69
100 words
D200 ~ D299
Output
0x68
100 words
D3200 ~ D3299
Configuration
0x82
8 words
Refer to Config Data below
Connection 4
Input
0x6B
100 words
D300 ~ D399
