DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
D-2
D.1 Current Consumption of a Slim PLC/an Extension Module
Users can calculate the maximum current consumed by the combination of a slim PLC and
modules by means of the data in the table below.
D.1.1 Current supply and current consumption of a PLC (+24VDC)
Model
Internal maximum current
consumed (mA)
Maximum current consumed by
the external DIO (A) (The current
consumption of all inputs and
outputs is calculated.) #1
12SA211R 100 5.1
12SA211T 70 2.1
12SE11R 110 5.1
12SE11T 80 2.1
12SS211S 50 2.1
14SS211R 100 9.1
14SS211T 50 3.1
20SX211R 220 9.1
20SX211S 170 1.9
20SX211T 170 3.1
24SV11T2 170 3.8
26SE11R 160 18.1
26SE11T 90 6.1
26SE11S 90 6.1
28SA211R 155 18.1
28SA211T 85 6.1
28SS211R 150 18.1
28SS211T 85 6.1
28SV11R2 210 18.1
28SV11S2 170 3.8
28SV11T2 170 3.8
#1: The external maximum current consumed is estimated on the basis of a worst condition. It is
suggested that users should calculate the maximum current consumed according to the actual
arrangement.
