OPERATION
EPT031055 Issue 2 September 2017 3-35
Add an Image
To insert an image into the message:
(1) Press on the screen within a specific area of the Message Editor
where you require the item to appear. A cross hair will appear at this
location.
(2) Select the Image icon from the Add menu.
(3) An images folder stored in the printer will open.
(4) Browse for the required image.
(5) Select the green tick icon to insert the image.
Monochrome Bitmap (*.bmp), DXF (*.dxf) (up to Version 12, information
about 3-dimensional objects is discarded, fonts and labels are not
supported) and Hewlett Packard Graphics Language HPGL (*.plt) black
white graphic file formats are supported.
Supported commands for HPGL import are: Arc Absolute, Arc Relative, Plot
Absolute, Plot Relative, Pen Up, Pen Down
(6) Select the Move icon to move the copied item to the desired
location within the message.
(7) Activate the message for printing by sending it to the printer via
the File menu .
Use the File Manager (Home > Settings > File Manager) to copy an
image from a USB device to the controller.
Image Object Properties
Force Reload - Tries to reload the imported graphic at message load. When
a graphic has been updated the new graphic is loaded into the message.
Resolution (dpi) - Sets the resolution in dots per inch (dpi) of the lines that
make up the graphic file.
Bitmap Algorithm - Specifies how the graphic is marked. Options include
horizontal, vertical and outline.
Inverse - Generates the inverse of the graphic. Necessary if the marking on
the substrate is to be highlighted. Has no effect in Outline mode.
