Domino F Series User Manual

TECHNICAL REFERENCE
EPT031055 Issue 2 September 2017 4-7
F-Series Laser Marking System
*Characters per second and production line speeds are substrate and
code dependent
**Dimensions measured overall for shortest version (without shutter)
F-Series Models F720i 10mm Scan Head
Maximum
Average Laser Power
70W
Laser Type
Pulsed Fibre Laser
Fixed Waveform
Peak Wavelength 1062 ± 3nm
Pulse Peak Power 13kW
Code Types Logos, bar codes, 2D codes, graphics, text, etc.
Characters per
second*
2000*
Product Line Speed*
600m/min*
(1970ft/min)
Character Height
0.3mm – field size
(0.01inch – field size)
Focal Length 160, 250, 300 [mm]
Marking Field
118x118 [mm], 187x187 [mm], 229x229[mm]
4.65x.4.65 [inch], 7.36x7.36 [inch], 9x9 [inch]
Fonts 24 fonts, multi--language including full Unicode
Scan Head
i-Tech Scan Head, mountable in various
orientations including axial and radial
Laser Head
Stainless steel and anodised aluminium
construction
Dimensions **
(L x W x H)
Laser: 460 x 80 x 141 [mm] (18.1 x 3.1 x 5.6 [in])
Controller: 405x560x430 [mm] (16x22x17 [inch])
Controller water cooled: 405x680x430 [mm]
(16x26.8x17 [inch])
Weight
Laser: 6.7 kg (14.8 lbs)
Controller: 40kg (88.2 lbs)
Controller (water cooled): 50.3kg (111lbs)
Fibre Length 2.70m (8.9 ft)
Operating Temp.
5° to 35° C (41° to 95°F)
Water Cooled: 5° to 45° C (41° to 113°F)
Environmental
Humidity
Max. 90% RH, non-condensing
Cooling
Laser: None or Water (max. 5 bar)
Controller: Fan or Water (max. 5 bar)
