INSTALLATION INSTRUCTIONS
2-30 EPT031055 Issue 2 September 2017
X28 Connector Schematic - Air Chiller Control
LogicRelay
switching ON
Laser - Controller Customer
Airkit/ Chiller
GND
+
1
2
3
4
5
6
(12V)
Source
24V
to the other connector s
Sum Load max 500mA
Input Air OK
Air OK respectively water level OK
Chiller OK
Input Chiller OK
1
2
3
4
5
6
X28 plug solder side
1
2
4
3
Outpu t Air/Chiller ON
4k4
4k4
together with X4
