Vigor2120 Series User’s Guide
555
T
T
e
e
l
l
n
n
e
e
t
t
C
C
o
o
m
m
m
m
a
a
n
n
d
d
:
:
w
w
o
o
l
l
This command allows Administrator to set the white list of WAN IP addresses/Subnets, that
the magic packet from these IP addresses/Subnets will be eligible to pass through NAT and
wake up the LAN client. You also need to set NAT rule for LAN client.
wol up [MAC Address]/[IP Address]
wol fromWan [on/off/any]
wol fromWan_Setting [idx][ip address][mask]
S
S
y
y
n
n
t
t
a
a
x
x
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
Parameter Description
MAC Address
It means the MAC address of the host.
IP address
It means the LAN IP address of the host. If you want to wake
up LAN host by using IP address, be sure that that IP address
has been bound with the MAC address (IP BindMAC).
on/off/any
It means to enable or disable the function of WOL from
WAN.
on: enable
off: disable
any: It means any source IP address can pass through NAT
and wake up the LAN client.
This command will allow the user to choose whether WoL
packets can be passed from the Internet to the LAN network
from a specific WAN interface.
[idx][ip address] [mask]
It means the index number (from 1 to 4).
These commands will allow the user to configure the LAN
clients that the user may wake up from the Internet through
the use of the WoL packet.
ip address - It means the WAN IP address.
mask - It means the mask of the IP address.
E
E
x
x
a
a
m
m
p
p
l
l
e
e
> wol fromWan on
% wol fromWan: on
> wol fromWan_Setting 1 192.168.1.45 255.255.255.0
% wol fromWan_Setting 1 192.168.1.45 255.255.255.0
T
T
e
e
l
l
n
n
e
e
t
t
C
C
o
o
m
m
m
m
a
a
n
n
d
d
:
:
a
a
p
p
p
p
q
q
o
o
s
s
The command is used to configure QoS for APP.
appqos view
appqos enable[0/1]
appqos traceable [-v | -e AP_INDEX CLASS | -d AP_INDEX]
appqos untraceable
appqos show_config [-t |–u]
