Ecotech A Series User Manual

CHAPTER 2, INSTALLATION AND OPERATION
98307600 Rev. C-1 2-11
 Down arrow key ()
Moves the cursor to the next menu item or, in an input field, moves the cursor
to the next choice or decrements the digit in a numerical field.
 <Select>
Selects the menu choice or selects the field for input.
 <Pg Up>
Moves the cursor to the previous page or screen.
 <Exit>
Leaves a field without making a change or returns the cursor to the main
screen.
 <Enter> (↵)
Confirms a menu item or a field selection to the microprocessor.
2.3.2 Using the Menu and Making Entries
The EC9830 analyzer is programmed with a series of menus that allows the
operator to view parameters, such as those generated by the microprocessor, or to
enter digital parameters, when appropriate, or to select from among the choices
displayed.
The cursor is displayed as a moveable highlighted area of text. (Letters appear as
the opposite of the rest of the text on the screen.)
2.3.2.1 Screen Fields
Screen fields that allow input are of two types:
 Choice fields
Contain a fixed series of choices in a wraparound scrolling format.
 Digit fields
Fields of programmable digital parameters in either wraparound scrolling or
non-wraparound scrolling format.
To select from among the choices in a choice field, first press the <Select> key to
designate the field, then use the Up and Down arrow keys to highlight the desired
selection. When the desired selection is displayed, press the <Enter> key to
confirm the entry.
To set digits in a digit field, first press the <Select> key to designate the field and
to highlight the different digits in the field. When the cursor indicates the digit you
wish to change, press the Up or Down arrow key until the desired digit appears.
