Ecotech A Series User Manual

CHAPTER 2, INSTALLATION AND OPERATION
98307600 Rev. C-1 2-31
INTERFACE MODE
This establishes the RS232 communication mode. Choices are COMMAND or
TERMINAL. TERMINAL uses the menu structure, and COMMAND uses the EC Serial
Command Set.
MULTIDROP BAUD
The communication rate for RS232 (DB9) connectors on rear panel. The available
rates are 1200, 2400, 4800, 9600, 19200 and 38400.
DATA LENGTH
Sets the number of data bits used in serial transmissions. The available lengths are
7 and 8.
STOP BITS
Sets the number of stop bits used in serial transmissions. The available number of
stop bits are 1 and 2.
PARITY
Sets the parity used in serial transmissions. The available choices are NONE,
EVEN, and ODD.
COMM. PROTOCOL
Sets the communication protocol in serial transmissions. The available choices are
ORIGINAL, BAVARIAN, and ENHANCED. See the serial communications
information in Chapter 4, Digital Communication.
2.5.14 Analog Output Menu
The ANALOG OUTPUT MENU contains settings that relate to the recording devices.
For a detailed explanation of the analog output, see section 2.6.3 below. The
setting of analog output ranges has no impact on the measurement range of the
analyzer; it only affects the analog output scaling.
2.5.14.1 CO Current Output Menu
CO OUTPUT MENU
RANGE : 50.00 PPM
OUTPUT TYPE : CURRENT
CURRENT RANGE : 0-20 MA
FULL SCALE : 0.00 %
ZERO ADJUST : 0.00 %
OVER RANGE : 200.00 PPM
OVER-RANGING : DISABLED
Figure 2-21. Analog Output Menu
