CHAPTER 2, INSTALLATION AND OPERATION
98307600 Rev. C-1 2-15
2.5 Menus and Screens
This section illustrates the various menus and screens for the EC9830 analyzer.
The B series menu structure will be very similar in structure yet will not have
some of the options that are available in the A series (These will be made clear
throughout the relevant sections) A short description of each menu and screen is
also provided. The entire menu structure is shown in Figure 2-6 below.
Figure 2-6. Menu Structure
INSTRUMENT MENU
CALIBRATION MENU
TEST MENU
INTERFACE MENU
TREND SELECT MENU
EVENT LOG
INSTRUMENT STATUS
SYSTEM TEMPERATURES
SYSTEM FAULTS
MAIN MENU
CALIBRATION:(MANUAL)
CAL MODE
CALIBRATION
BACKGROUND
BACK INTERVAL
CALIBRATION:(TIMED)
TIMER INTERVAL
STARTING HOUR
CYCLE TIME
CO TIMED SPAN
CALIBRATION
SPAN COMP
CO SPAN RATIO
BACKGROUND
BACK INTERVAL
CONCENTRATION
REFERENCE
SAMPLE PRESSURE
GAS FLOW
GAS PRESSURE
REF. VOLTAGE
CONC. VOLTAGE
DIGITAL SUPPLY
CELL TEM.
CONV. TEMP.
CHASSIS TEMP.
FLOW TEMP.
COOLER TEMP.
MIRROR TEMP.
CELL TEMPERATURE
SAMPLE GAS FLOW
FLOW BLOCK TEMP
12 VOLT SUPPLY
REFERENCE VOLTAGE
CONVERTER TEMP
COOLER & IR SOURCE
CHOPPER WHEEL
MIRROR TEMP.
MEASUREMENT MENU
DATE
TIME
PASSWORD
ERASE MEMORY
UNIT SELECTION
CONVERSION TEMP
DECIMAL PLACES
NOISE
OUTPUT TYPE
OFFSET
FULL SCALE
ZERO ADJUST
OVER RANGE
INST. DATA
TOTAL CAPACITY
DATA LOGGING MENU
MAIN GAS ID
INTERFACE MODE
DATA LENGTH
STOP BITS
PARITY
COMM. PROTOCOL
NETWORK ADAPTOR
OUTPUT TEST MENU
DIAGNOSTIC MENU
CALCULATION FACTORS
MEASUREMENT GAIN
PRES/TEMP/FLOW COMP
DIAGNOSTIC MODE
CONTROL LOOP
TEST MEASURE
PREPROCESSOR POTS
FLOW CONTROL POTS
INT. VALVE #1
INT. VALVE #2
INT. VALVE #3
EXT. MEASURE
EXT. ZERO GAS
EXT. SPAN GAS
MEASURE COARSE ZERO
MEASURE FINE ZERO
INPUT
TEST REFERENCE
TEST MEASURE
REF. VOLTAGE
CO
MULTIDROP PORT TEST
WATCHDOG TEST
DISPLAY TEST
FLOW CONTROL ZERO
FAN SPEED CONTROL
PUMP SPEED FINE
PUMP SPEED COARSE
GAS FLOW
To Next Page
