Description of the Individual Menu Items
The following types are available:
selected the printer switches automatically between the parallel and
serial interface. The first data received at the port determine which
interface port becomes active. The other interface port will be closed so
that only one interface is active at a time (for detailed information see
A Interface Description).
The factory settings for the interface type are: PARALL./RS232, 8 bit
word length, 9600 baud rate, even parity bit, DTR protocol, ignore
DSR+CTS, and 64 Kbyte Buffer.
(Only indicated if the serial interface is selected)
Number of bits that represent a word; values are 7 or 8 bit
(Only indicated if the serial interface is selected)
Controls the speed of data transfer. Possible transfer rates are: 600,
1200, 2400, 4800, 9600, 19200 or 38400 bps.
(Only indicated if the serial interface is selected)
The data transfer will be checked by an even or odd parity bit. The
(Only indicated if the serial interface is selected)
The setting switches automatically from DTR to XON/XOFF if I/F
