Epson TM-m30III User Manual

63
Chapter 2 Setup
Passing Cables through the Rear Center
Remove the cable slot cover, and then pass cables through the slot.
Passing Cables through the Left or Right
With your fingers, fold the tab on the side you want to pass cables and remove it to make a slot. If the slot is
jagged, smooth it out with nippers or a file to prevent the cables from being damaged.
Once the tabs are removed, they cannot be put back on. Make sure to decide how to route the cables before
removing the tab.
The cable slot cover, which was removed from the center of the rear, can be reattached. To reattach
the cover, hook the tab of the cover onto the rear cover, and then push the other side in.
Tab
Rear cover

Epson TM-m30III Specifications

General

Type	POS printer
Print technology	Thermal
Maximum resolution	203 x 203 DPI
USB port	Yes
Serial interface	-
Connectivity technology	Wired & Wireless
Ethernet LAN	No
Internal memory	- MB
Product color	White
Mobile operating systems supported	Android, iOS
