2. Dimensions
2-1. Models: AOYG72LRLA and AOYG90LRLA
Unit: mm
Top view
Front view Rear viewSide view
Bottom view
196 688
515.5
40.5
39
196
1,080
1,428
23.5
A
1,017
1,102
40 480 12
B
C
447
479
Terminal blocks (Power)
- 145 -
2-1. Models: AOYG72LRLA and AOYG90LRLA 2. Dimensions
OUTDOOR UNIT
AOYG72-90LRLA
OUTDOOR UNIT
AOYG72-90LRLA
