Fujitsu Ceiling Type Design & Technical Manual

6. Fan performance
6-1. Slim duct type
¢
Model: ARYG18LLTB
Hi (SP mode 09)
Hi (Normal SP)
SP mode 09
upper limit
SP mode 09
lower limit
Quiet (SP mode 09)
Normal SP
upper limit
Quiet (Normal SP)
SP mode 00
upper limit
Quiet (SP mode 00)
110
100
90
80
70
60
50
40
30
20
10
0
700
External static pressure (Pa)
Airflow (m
3
/h)
Hi (SP mode 00)
900
1,000
1,100
1,200800600
110
100
90
80
70
60
50
40
30
20
10
0
External static pressure (Pa)
Airflow (m
3
/h)
Hi (SP mode 09)
Hi (SP mode 08)
Hi (SP mode 07)
Hi (SP mode 06)
Hi (SP mode 05)
Hi (SP mode 04)
Hi (SP mode 03)
Hi (Normal SP)
Hi (SP mode 02)
Hi (SP mode 01)
Hi (SP mode 00)
Available airflow rate range (High level)
*1
700
900 1,000 1,100
1,200
800
600
*1: Available airflow rate range when Auto louver grille (option) is installed.
Fan speed: HIGH
Vertical airflow direction louver: Up
- 53 -
6-1. Slim duct type 6. Fan performance
